F30 03 4 Start-up
HI 800 473 E Rev. 1.00 Page 33 of 46
4.3.4.2 Tab: DO 20: Channels
The DI 20: Channels tab contains the following system parameters.
System parameter
Data
Type
R/W Description
Channel no. --- R Channel number, defined by default
-> Error Code
[BYTE]
BYTE R Error codes for the digital input channels
Coding Description
0x01 Fault in the analog input module
0x10 Short-circuit of the channel
0x80
Intermittence between pulsed output DO
and digital input DI, e.g.,
Open-circuit
Open switch
L+ undervoltage
-> Value [BOOL] BOOL R Input values for the digital input channels
0 = input de-energized
1 = input energized
Pulsed Output
[USINT] ->
USINT W Source channel for pulsed supply
Coding Description
0 Input channel
1 Pulse of the 1st DO channel
2 Pulse of the 2nd DO channel
… …
8 Pulse of the 8th DO channel
Table 25: System Parameters for Digital Inputs, DI 20: Channels Tab
