3 Product Description F30 03
Page 22 of 46 HI 800 473 E Rev. 1.00
3.5 Product Data
General
Total program and data memory
for all application programs
5 MB less 64 kBytes for CRCs
Response time
≥ 6 ms
Ethernet interfaces 4 x RJ-45, 10/100BaseT (with 100 Mbit/s)
with integrated switch
Fieldbus interfaces 3 x 9-pole D-sub
FB1 and FB2 with fieldbus submodule pluggable,
FB3 with RS485 for Modbus (master or slave) or
ComUserTask
Operating Voltage 24 VDC, -15...+20 %, r
PP
≤ 15 %,
from a power supply unit with safe insulation
in accordance with IEC 61131-2
Current input max. 8 A (with maximum load)
Idle: 0.5 A
Fuse (external) 10 A time-lag (T)
Buffer for date/time Gold capacitor
Operating temperature 0 °C...+60 °C
Storage temperature -40 °C...+85 °C
Type of protection IP20
Max. dimensions
(without plug)
Width: 257 mm (with housing screws)
Height: 114 mm (with fixing bolt)
Depth: 66 mm (with earthing screw)
Weight approx. 1.2 kg
Table 12: Product Data
Digital inputs
Number of inputs 20 (non-galvanically isolated)
High level: Voltage
Current input
15...30 VDC
≥ 2 mA at 15 V
Low level: Voltage
Current input
max. 5 VDC
max. 1.5 mA (1 mA at 5 V)
Switching point typ. 7.5 V
Supply 5 x 20 V / 100 mA (at 24 V), short-circuit-proof
Table 13: Specifications for Digital Inputs
