F30 03 4 Start-up
HI 800 473 E Rev. 1.00 Page 27 of 46
4.3 Configuring the Controller with SILworX
In the Hardware Editor, the controller is represented like a base plate equipped with the
following modules:
 Processor module (CPU)
 Communication module (COM)
 Input module (DI 20)
 Output module (DO 8)
Double-click the module to open the detail view with the corresponding tabs. The tabs of
the I/O modules are used to assign the global variables configured in the user program to
the system variables.
4.3.1 Processor Module
The following tables present the parameters for the processor module (CPU) in the same
order as given in the Hardware Editor. The Content of the registers Module and Routings of
the processor module and the communication module is identical.
4.3.1.1 Tab: Module
The Module tab contains the following parameters:
Parameter Description
Name Module name
Use Max. µP Budget for
HH Protocol
 Activated: Use CPU load limit from the Max. µP Budget for
HH Protocol [%] field.
 Deactivated: Do not use the CPU Load limit for safeethernet.
Default setting: Deactivated
Max. µP Budget for HH
Protocol [%]
Maximum CPU load of module that can be used for processing
the safeethernet protocols.
i
The maximum load must be distributed among all the
implemented protocols that use this communication
module.
IP Address IP address of the Ethernet interface.
Default value: 192.168.0.99
Subnet Mask
32 bit address mask to split up the IP address in network and
host address.
Default value: 255.255.252.0
Standard Interface
Activated: the interface is used as standard interface for the
system login.
Default setting: Deactivated
Default Gateway IP address of the default gateway.
Default value: 0.0.0.0
