4.3.5.2 Tab: DO 8: Channels
The DO 8: Channels tab contains the following system parameters.
System parameter
Data
Type
R/W Description
Channel no. --- R Channel number, defined by default
-> Error Code
[BYTE]
BYTE R Error codes for the digital output channels
Coding Description
0x01 Fault in the digital output module
0x02 Channel shutdown due to overload
0x04 Error while reading back the digital outputs
0x08
Error while reading back the status of the
digital outputs
Value [BOOL] -> BOOL W Output value for DO channels:
1 = output energized
0 = output de-energized
Table 27: System Parameters for Digital Outputs, DO 8: Channels Tab
