F30 03 3 Product Description
HI 800 473 E Rev. 1.00 Page 23 of 46
Digital outputs
Number of outputs 8 (non-galvanically isolated)
Output voltage ≥ L+ minus 2 V
Output current Channels 1...3 and 5...7: 0.5 A at 60 °C
Channels 4 and 8: 1 A at 60 °C, 2 A at 50 °C)
Minimum load 2 mA for each channel
Internal voltage drop max. 2 V at 2 A
Leakage current (with low
level)
max. 1 mA at 2 V
Behavior upon overload
The affected output is switched off and cyclically switched
on again
Total output current max. 7 A
Upon overload, all outputs are switched off and cyclically
switched on again
Table 14: Specifications for the Digital Outputs
3.6 Certified HIMatrix F30
HIMatrix F30
CE EMC,
TÜV IEC 61508 1-7:2010 up to SIL 3
IEC 61511:2004
EN ISO 13849-1:2008
IEC 62061:2005
EN 50156-1:2004
EN 298:2003
EN 230:2005
PROFIBUS
Nutzerorganisation (PNO)
Test Specification for PROFIBUS DP Slave,
Version 3.0 November 2005
Table 15: Certificates
Further safety standards and application standards are specified in the certificate. The
certificate and the EC Type-Examination Certificate are available on the HIMA website at
www.hima.com.
