HIMA HIMatrix F30 03 User Manual

4 Start-up F30 03
Page 34 of 46 HI 800 473 E Rev. 1.00
4.3.5 Digital Outputs for F30
The following tables present the statuses and parameters for the output module (DO 8) in
the same order given in the SILworX Hardware Editor.
4.3.5.1 Tab: Module
The Module tab contains the following system parameters:
System parameter
Data
Type
R/W Description
DO.Error Code WORD R Error codes for all digital outputs
Coding Description
0x0001 Fault within the digital outputs
0x0002 MOT test of safety shutdown returns a fault
0x0004 MOT test of auxiliary voltage returns a fault
0x0008 FTT test of test pattern faulty
0x0010 MOT test of output switch test pattern faulty
0x0020
MOT test of output switch test pattern
(shutdown test of the outputs) faulty
0x0040 MOT test active shutdown via WD faulty
0x0200
All outputs are switched off, total current
exceeded
0x0400
FTT test: 1st temperature threshold
exceeded
0x0800
FTT test: 2nd temperature threshold
exceeded
0x1000
FTT test: Monitoring of auxiliary voltage 1:
Undervoltage
Module.Error Code WORD R Module error code
Coding Description
0x0000
I/O processing, if required with errors, see
other error codes
0x0001 No I/O processing (CPU not in RUN)
0x0002 No I/O processing during the booting test
0x0004 Manufacturer interface operating
0x0010 No I/O processing: invalid configuration
0x0020 No I/O processing: fault rate exceeded
0x0040/
0x0080
No I/O processing: configured module not
plugged in
Module.SRS UDINT R Slot number (System Rack Slot)
Module.Type UINT R
Type of module, target value: 0x00B4 [180
dec
]
Table 26: System Parameter for Digital Outputs, Module Tab
