3 Product Description F3 DIO 16/8 01
Page 26 of 60 HI 800 177 E Rev. 2.00
3.5 Product Data
General
Response time ≥ 10 ms
Ethernet interfaces
2 x RJ-45, 10BASE-T/100BASE-Tx with integrated
switch
Operating voltage 24 VDC, -15...+20 %, r
PP
≤ 15 %,
from a power supply unit with safe insulation
in accordance with IEC 61131-2
Current input max. 11 A (with maximum load)
for UL, only 10 A allowed
Idle current: 0.45 A
Fuse (external) 12 A time-lag (T)
Operating temperature 0...+60 °C
Storage temperature -40...+85 °C
Type of protection IP20
Max. dimensions
(without plug)
Width: 205 mm (with housing screws)
Height: 114 mm (with fixing bolt)
Depth: 88 mm (with earth)
Weight approx. 1.3 kg
Table 12: Product Data of F3 DIO 16/8 01
Digital inputs
Number of inputs 16 (non-galvanically separated)
Low level: voltage
current input
15...30 VDC
≥ 2 mA at 15 V
Low level: voltage
current input
max. 5 VDC
max. 1.5 mA (1 mA at 5 V)
Switching point typ. 7.5 V
Switching time 250 µs
Supply 4 x LS+ minus 4 V / 40 mA, short-circuit-proof
Buffered for 20 ms
2x LS+ minus 2 V / 1 A total, short-circuit-proof,
unbuffered
Current input: max. 1 A at 60 °C
Table 13: Specifications for the Digital Inputs
