HIMA HIMatrix User Manual

4 Start-up F3 DIO 16/8 01
Page 40 of 60 HI 800 177 E Rev. 2.00
4.3.4 Pulsed Outputs for F3 DIO 16/8 01
The following table presents the statuses and parameters for the pulse module (DO 2 01) in the
same order given in the SILworX Hardware Editor.
4.3.4.1 Tab: Module
The Module tab contains the following system parameters:
System parameter
Data
type
R/W Description
DO.Error Code WORD R Module error code
Coding Description
0x0001 Error of the TO unit as a whole:
Module Error Code WORD R Module error code
Coding Description
0x0000
I/O processing, if required with errors, see
other error codes
0x0001 No I/O processing (remote I/O not in RUN)
0x0002 No I/O processing during the booting test
0x0004 Manufacturer interface operating
0x0010 No I/O processing: invalid configuration
0x0020 No I/O processing: fault rate exceeded
0x0040/
0x0080
No I/O processing: configured module not
plugged in
Module SRS UDINT R Slot number (System Rack Slot)
Module Type UINT R Type of module, target value: 0x00D3 [211
dec
]
Table 28: SILworX - System Parameters for Pulsed Outputs, Module Tab
4.3.4.2 Tab: DO 2 01: Channels
The DO 2 01: Channels tab contains the following system parameters.
System parameter Data type R/W Description
Channel no. --- R Channel number, defined by default
-> Error Code [BYTE] BYTE R Error code of the individual digital pulsed output channels:
Coding Description
0x01 Fault in the digital output module
Value [BOOL] -> BOOL R Output value for TO channels:
Coding Description
FALSE Output de-energized
TRUE Output energized
Do not use pulsed outputs as safety-related outputs!
Table 29: SILworX - System Parameters for Pulsed Outputs, Channels Tab
