4 Start-up F3 DIO 16/8 01
Page 38 of 60 HI 800 177 E Rev. 2.00
System parameter
Data
type
R/W Description
DO.[xx][xx].in pairs BOOL W
Common ground for each pair
(DO- outputs form the common ground)
Coding Description
FALSE No common ground for each pair
TRUE No common ground for each pair
Default value: 0
Pair 1 = Channel 1 [01] and channel 2 [02]
Pair 2 = Channel 3 [03] and channel 4 [04]
Pair 3 = Channel 5 [05] and channel 6 [06]
Pair 4 = Channel 7 [07] and channel 8 [08]
Module Error Code WORD R Module error code
Coding Description
0x0000
I/O processing, if required with errors, see
other error codes
0x0001 No I/O processing (remote I/O not in RUN)
0x0002 No I/O processing during the booting test
0x0004 Manufacturer interface operating
0x0010 No I/O processing: invalid configuration
0x0020 No I/O processing: fault rate exceeded
0x0040/
0x0080
No I/O processing: configured module not
plugged in
Module SRS UDINT R Slot number (System Rack Slot)
Module Type UINT R Type of module, target value: 0x00C4 [196
dec
]
Table 26: SILworX - System Parameters for Digital Outputs, Module Tab
