4.4.3 Digital Inputs of F3 DIO 16/8 01
System Signal R/W Description
Mod.SRS [UDINT] R Slot number (System Rack Slot)
Mod. Type [UINT] R Type of module, target value: 0x00E2 [226
dec
]
Module error code
0x0000
I/O processing, if required with errors, see other error
codes
0x0001 No I/O processing (remote I/O not in RUN)
0x0002 No I/O processing during the booting test
0x0004 Manufacturer interface operating
0x0010 No I/O processing: invalid configuration
0x0020 No I/O processing: fault rate exceeded
Mod. Error Code [WORD] R
0x0040/
0x0080
No I/O processing: configured module not plugged in
Error code of the DI supply unit as a whole
DI.Error Code Supply
[WORD]
R
0x0001 Module fault
Error codes of the single DI supplies
0x01 Error DI supply unit
0x02 Supply shutdown due to overcurrent
DI[xx].Error Code Supply
[BYTE]
R
0x04 Error while reading back the supply
Error codes for all digital inputs
0x0001 Fault within the digital inputs
DI.Error Code [WORD] R
0x0002 FTT test of test pattern faulty
Error codes for the digital input channels
0x01 Fault in the analog input module
0x10 Short-circuit of the channel
DI[xx].Error Code [BYTE] R
0x80
Intermittence between pulsed output TO and digital input
DI, e.g.,
 Open-circuit
 Open switch
 L+ undervoltage
Input values for the digital input channels
0 Input de-energized
DI[xx].Value [BOOL] R
1 Input energized
Number of pulsed outputs (supply outputs)
0 No pulsed output planned for SC/OC
1)
detection
1 Pulsed output 1 planned for SC/OC
1)
detection
2 Pulsed output 1 and 2 planned for SC/OC
1)
detection
DI Number of
Pulsed Channels [USINT]
W
Pulsed outputs must not be used as safety-related outputs!
Triggering the single DI supplies
0 Sensor supply (1 A) is off.
1 Sensor supply (1 A) is on.
DI Supply[xx] [BOOL] W
Default setting 0: Feeding current 40 mA
DI Pulse.Slot [UDINT] W Pulse module slot
(SC/OC
1)
detection), set the value to 3
Source channel for pulsed supply
0 Input channel
1 Pulse of the 1st TO channel
DI[xx].Pulsed Channel
[USINT]
W
2 Pulse of the 2nd TO channel
