HIMA HIMatrix User Manual

4 Start-up F3 DIO 16/8 01
Page 32 of 60 HI 800 177 E Rev. 2.00
4.1.5 Cable Plugs
Cable plugs attached to the pin headers of the devices are used to connect to the power supply
and to the field zone. The cable plugs are included within the scope of delivery of the HIMatrix
devices and modules.
The devices power supply connections feature the following properties:
Connection to the power supply
Cable plugs Four poles, screw terminals
Wire cross-section 0.2…2.5 mm
2
(single-wire)
0.2…2.5 mm
2
(finely stranded)
0.2…2.5 mm
2
(with wire end ferrule)
Stripping length 10 mm
Screwdriver Slotted 0.6 x 3.5 mm
Tightening torque 0.4…0.5 Nm
Table 22: Power Supply Cable Plug Properties
Connection to the field zone
Number of cable plugs 2 pieces, eight poles, screw terminals
4 pieces, ten poles, screw terminals
Wire cross-section 0.2…1.5 mm
2
(single-wire)
0.2…1.5 mm
2
(finely stranded)
0.2…1.5 mm
2
(with wire end ferrule)
Stripping length 6 mm
Screwdriver Slotted 0.4 x 2.5 mm
Tightening torque 0.2…0.25 Nm
Table 23: Input and Output Cable Plug Properties
