HIMA HIMatrix User Manual

F3 DIO 16/8 01 3 Product Description
HI 800 177 E Rev. 2.00 Page 27 of 60
Digital outputs
Number of outputs 8 (non-galvanically separated)
2-pole switching
DO+ 2 A (inrush current typ. 10 A at 2 ms)
DO- 2 A (inrush current typ. 10 A at 2 ms)
Output voltage ≥ L+ minus voltage drop (L+ and L- leg)
Voltage drop
2-pole outputs
max. 3 V at 2 A
Voltage drop
Outputs DO+
max. 1.5 V at 2 A
Voltage drop
Outputs DO-
max. 1.5 V at 2 A
Output current,
see also Table 11
max. 2 A at <
40 °C
max. 1 A at 40…60 °C
min. 10 mA
Total permissible current max. 8 A
Leakage current (with low level) max. 1 mA at 2 V
Lamp load max. 25 W
Inductive load max. 500 mH
Open-circuit
> 4 k
Line Diagnosis
Short-circuit
< 10 
Behavior upon overload The affected output is switched off and
cyclically switched on again
Table 14: Specifications for the Digital Outputs
Pulsed outputs
Number of outputs 2 (non-galvanically separated)
Output voltage
 L+ minus 4 V
Output current approx. 60 mA
Minimum load None
Switching time
 100 µs
Behavior upon overload
2 x  19.2 V, short-circuit current 60 mA at 24 V
Table 15: Specifications for the Pulsed Outputs
3.5.1 Product Data F3 DIO 16/8 014
The F3 DIO 16/8 014 model variant is intended for use in railway applications. The electronic
components are coated with a protective lacquer.
F3 DIO 16/8 014
Operating temperature -25…+70 °C (temperature class T1)
Output current
The output current of the digital outputs depends on the
ambient temperature.
Ambient temperature Output current
< 40 °C 2 A
40…60 °C 1 A
> 60 °C 0.5 A
Weight approx. 1.3 kg
Table 16: Product Data of F3 DIO 16/8 014
