F3 DIO 16/8 01 4 Start-up
HI 800 177 E Rev. 2.00 Page 45 of 60
4.4.5 Pulsed Outputs for F3 DIO 16/8 01
System Signal R/W Description
Mod.SRS [UDINT] R Slot number (System Rack Slot)
Mod. Type [UINT] R Type of module, target value: 0x00D3 [211
dec
]
Module error code
0x0000 I/O processing, if required with errors
see other error codes
0x0001 No I/O processing (remote I/O not in RUN)
0x0002 No I/O processing during the booting test
0x0004 Manufacturer interface operating
0x0010 No I/O processing: invalid configuration
0x0020 No I/O processing: fault rate exceeded
Mod. Error Code [WORD] R
0x0040/
0x0080
No I/O processing: configured module not plugged in
Error code of the TO unit as a whole DO.Error Code [WORD] R
0x0001 Error of the TO unit as a whole:
Error code of the individual digital pulsed output channels: DO[xx].Error Code [BYTE] R
0x01 Fault in the digital output module
Output value for TO channels:
0 Output de-energized
1 Output energized
DO[xx].Value [BOOL] W
Pulsed outputs must not be used as safety-related outputs!
Table 32: ELOP II Factory - System Signals for the Pulsed Outputs
