5.2 General Specifications
137
Basic Specifications
Display Specifications
Rated supply voltage 100 VAC to 240 VAC (Voltage fluctuations of ±10% from the rated supply voltage are
taken into account.)
Anticipated transient overvoltage: 2500 V
Rated power supply frequency 50/60 Hz
Maximum rated power 40 VA or less
Dimensions Approx. 305 (W) × 132 (H) × 256 (D) mm (12.01”W × 5.20”H × 10.08”D)
(excluding protrusions)
Mass PW3336 series Approx. 5.2 kg (183.4 oz.)
PW3337 series Approx. 5.6 kg (197.5 oz.)
Display 7-segment LED
Number of display parameters 4
Display resolution Other than integrated values: 99999 count
Integrated values: 999999 count
Display update rate 200 ms ±50 ms (approx. 5 updates per sec.) to 20 s (varies with number of averaging
iterations setting)
Power ranges For wiring modes other than 1P2W, sum power range (power ranges for individual channels are the same
as for 1P2W).
Current/Wiring/Voltage 15.000 V 30.000 V 60.000 V 150.00 V 300.00 V 600.00 V 1.0000 kV
200.00 mA
1P2W 3.0000 6.0000 12.000 30.000 60.000 120.00 200.00
Other than 1P2W, 3P4W 6.0000 12.000 24.000 60.000 120.00 240.00 400.00
3P4W 9.0000 18.000 36.000 90.000 180.00 360.00 600.00
500.00 mA
1P2W 7.5000 15.000 30.000 75.000 150.00 300.00 500.00
Other than 1P2W, 3P4W 15.000 30.000 60.000 150.00 300.00 600.00 1.0000 k
3P4W 22.500 45.000 90.000 225.00 450.00 900.00 1.5000 k
1.0000 A
1P2W 15.000 30.000 60.000 150.00 300.00 600.00 1.0000 k
Other than 1P2W, 3P4W 30.000 60.000 120.00 300.00 600.00 1.2000 k 2.0000 k
3P4W 45.000 90.000 180.00 450.00 900.00 1.8000 k 3.0000 k
2.0000 A
1P2W 30.000 60.000 120.00 300.00 600.00 1.2000 k 2.0000 k
Other than 1P2W, 3P4W 60.000 120.00 240.00 600.00 1.2000 k 2.4000 k 4.0000 k
3P4W 90.000 180.00 360.00 900.00 1.8000 k 3.6000 k 6.0000 k
5.0000 A
1P2W 75.000 150.00 300.00 750.00 1.5000 k 3.0000 k 5.0000 k
Other than 1P2W, 3P4W 150.00 300.00 600.00 1.5000 k 3.0000 k 6.0000 k 10.000 k
3P4W 225.00 450.00 900.00 2.2500 k 4.5000 k 9.0000 k 15.000 k
10.000 A
1P2W 150.00 300.00 600.00 1.5000 k 3.0000 k 6.0000 k 10.000 k
Other than 1P2W, 3P4W 300.00 600.00 1.2000 k 3.0000 k 6.0000 k 12.000 k 20.000 k
3P4W 450.00 900.00 1.8000 k 4.5000 k 9.0000 k 18.000 k 30.000 k
20.000 A
1P2W 300.00 600.00 1.2000 k 3.0000 k 6.0000 k 12.000 k 20.000 k
Other than 1P2W, 3P4W 600.00 1.2000 k 2.4000 k 6.0000 k 12.000 k 24.000 k 40.000 k
3P4W 900.00 1.8000 k 3.6000 k 9.0000 k 18.000 k 36.000 k 60.000 k
50.000 A
1P2W 750.00 1.5000 k 3.0000 k 7.5000 k 15.000 k 30.000 k 50.000 k
Other than 1P2W, 3P4W 1.5000 k 3.0000 k 6.0000 k 15.000 k 30.000 k 60.000 k 100.00 k
3P4W 2.2500 k 4.5000 k 9.0000 k 22.500 k 45.000 k 90.000 k 150.00 k
Units: W (active power), VA (apparent power), var (reactive power)
