Hioki PW3336 - Switching between Analog Output and Waveform Output

3.8 Using D/A Output
92
Switching between analog output and waveform output
1 Press .
2 Press to display the settings
screen shown to the left.
3 Press or to change the out-
put method.
Std.: Standard output (analog output)
FASt: Fast output (waveform output)
4 Press to exit the settings.
The instrument will return to the normal mea-
surement state.
