5.3 Measurement specifications
139
Basic Measurement Specifications
5.3 Measurement specifications
Measurement method Simultaneous voltage and current digital sampling, zero-cross simultaneous calculation
Sampling frequency Approx. 700 kHz
A/D converter resolution 16-bit
Frequency bands DC, 0.1 Hz to 100 kHz (Reference value of 0.1 Hz ≤ f < 10 Hz)
Synchronization sources
(SYNC)
U1, U2, U3, I1, I2, I3, DC (fixed at 200 ms)
Can be set separately for each wiring mode.
When the source input AC measured value is less than 1% f.s., operation and accuracy
are not defined.
When synchronization cannot be detected, the SYNC ERROR lamp will light up.
Operation and accuracy are not defined at that time.
When the synchronization source is DC, accuracy is not defined for input with a cycle
that is not divisible by 200 ms.
Synchronization timeout setting: 0.1 sec. / 1 sec. / 10 sec. (linked to measurement lower
limit frequency setting)
Measurement items Voltage, current, active power, apparent power, reactive power, power factor, phase an-
gle, frequency, current integration, active power integration, integration time, voltage
waveform peak value, current waveform peak value, efficiency, voltage crest factor, cur-
rent crest factor, time average current, time average active power, voltage ripple rate,
current ripple rate
Harmonic parameters
Harmonic voltage RMS value, harmonic current RMS value, harmonic active power, to-
tal harmonic voltage distortion, total harmonic current distortion, fundamental wave volt-
age, fundamental wave current, fundamental wave active power, fundamental wave
apparent power, fundamental wave reactive power, fundamental wave power factor
(displacement power factor), fundamental wave voltage current phase difference, inter-
channel voltage fundamental wave phase difference, inter-channel current fundamental
wave phase difference, harmonic voltage content percentage, harmonic current content
percentage, harmonic active power content percentage
The following parameters can be downloaded as data with communications but not dis-
played:
Harmonic voltage phase angle, harmonic current phase angle, harmonic voltage cur-
rent phase difference
Rectifiers AC+DC AC+DC measurement Display of true RMS values for both voltage and
current
AC+DC Umn AC+DC measurement Display of average value rectified RMS convert-
ed values for voltage and true RMS values for
current
DC DC measurement Display of simple averages for both voltage and
current
Display of values calculated by (voltage DC val-
ue) × (current DC value) for active power
AC AC measurement Display of values calculated by
for both
voltage and current
Display of values calculated by
(AC+DC value) - (DC value) for active power
FND Extraction and display of the fundamental wave component from har-
monic measurement
Zero-Crossing Filter 100 Hz/ 500 Hz/ 5 kHz/ 200 kHz (linked to frequency measurement range)
100 Hz: 0.1 Hz to 100 Hz
500 Hz: 0.1 Hz to 500 Hz
5 kHz: 0.1 Hz to 5 kHz
200 kHz: 0.1 Hz to 200 kHz
The zero-cross filter lower limit setting is linked to the synchronization timeout setting.
10 Hz/ 1 Hz/ 0.1 Hz
(AC+DC value)
2
- (DC value)
2
