Hioki PW3336 - Page 38

2.2 Connecting the Measurement Lines
32
2 When measuring measurement lines that exceed the maximum input current
Connect the instrument using a current sensor.
(For wiring modes other than 1P2W, see "Wiring diagrams when using an external cur-
rent sensor" (p.173) in "5.6 Wiring Specifications".)
2
(1) (2)
2 When measuring measurement lines that exceed the maximum input, connect
the instrument using a VT (PT) and CT.
3
Corresponding with Method 1 (1) Corresponding with Method 2 (1)
