Hirschmann BAT series User Manual

66
Installation BAT
Release 05 03/2013
 Network range
 Power consumption/power output and order numbers
TP port
Length of a twisted pair segment max. 100 m/328 ft (for cat5e cable)
Table 12: TP port 10BASE-T / 100BASE-TX / 1000BASE-T
Device Power
consumption
Power output Order number
BAT54-F 10.0 W 34.1 Btu (IT)/h 943 959-112
BAT54-F FCC 10.0 W 34.1 Btu (IT)/h 943 959-012
BAT54-F X2 10.0 W 34.1 Btu (IT)/h 943 959-102
BAT54-F X2 FCC 10.0 W 34.1 Btu (IT)/h 943 959-002
BAT54-F Client 10.0 W 34.1 Btu (IT)/h 943 959-117
BAT54-F Client FCC 10.0 W 34.1 Btu (IT)/h 943 959-017
BAT54-F Single 10.0 W 34.1 Btu (IT)/h 943 959-116
BAT54-F Single FCC 10.0 W 34.1 Btu (IT)/h 943 959-016
BAT54-Rail 10.0 W 34.1 Btu (IT)/h 943 926-021
BAT54-Rail - FCC 10.0 W 34.1 Btu (IT)/h 943 926-022
BAT54-Rail - Japan 10.0 W 34.1 Btu (IT)/h 943 926-023
BAT54-Rail Client 10.0 W 34.1 Btu (IT)/h 943 926-521
BAT54-Rail Client (FCC) 10.0 W 34.1 Btu (IT)/h 943 926-522
BAT300-Rail 10.0 W 34.1 Btu (IT)/h 943 989-001
BAT300-Rail FCC 10.0 W 34.1 Btu (IT)/h 943 989-101
BAT300-F 10.0 W 34.1 Btu (IT)/h 943 959-118
BAT300-F FCC 10.0 W 34.1 Btu (IT)/h 943 959-018
BAT300-Rail BGN 10.0 W 34.1 Btu (IT)/h 943 989-105
BAT300-F BGN 10.0 W 34.1 Btu (IT)/h 943 959-218
BAT54-F Client BG 10.0 W 34.1 Btu (IT)/h 943 959-217
BAT54-F Single BG 10.0 W 34.1 Btu (IT)/h 943 959-216
BAT54-F BG 10.0 W 34.1 Btu (IT)/h 943 959-212
BAT54-F X2 BG 10.0 W 34.1 Btu (IT)/h 943 959-202
BAT54-Rail Client BG 10.0 W 34.1 Btu (IT)/h 943 926-205
BAT54-Rail BG 10.0 W 34.1 Btu (IT)/h 943 926-105
BAT54-Rail Single 10,0 W 34.1 Btu (IT)/h 943 926-721
BAT54-Rail Single (FCC) 10,0 W 34.1 Btu (IT)/h 943 926-722
BAT54-Rail Single BG 10,0 W 34.1 Btu (IT)/h 943 926-305
BAT300-F X2 10,0 W 34.1 Btu (IT)/h 943 959-108
BAT300-F X2 BGN 10,0 W 34.1 Btu (IT)/h 943 959-208
