Port Configuration
3-75
3
CLI – The following example configures LACP parameters for ports 1-6. Ports 1-4
are used as active members of the LAG; ports 5 and 6 are set to backup mode.
Console(config)#interface ethernet 1/1 4-123
Console(config-if)#lacp actor system-priority 3 4-140
Console(config-if)#lacp actor admin-key 120 4-141
Console(config-if)#lacp actor port-priority 128 4-142
Console(config-if)#exit
.
.
.
Console(config)#interface ethernet 1/6
Console(config-if)#lacp actor system-priority 3
Console(config-if)#lacp actor admin-key 120
Console(config-if)#lacp actor port-priority 512
Console(config-if)#end
Console#show lacp sysid 4-143
Channel Group System Priority System MAC Address
-------------------------------------------------------------------------
1 32768 00-00-E9-31-31-31
2 32768 00-00-E9-31-31-31
3 32768 00-00-E9-31-31-31
4 32768 00-00-E9-31-31-31
5 32768 00-00-E9-31-31-31
6 32768 00-00-E9-31-31-31
Console#show lacp 1 internal 4-143
Channel group : 1
-------------------------------------------------------------------------
Oper Key : 120
Admin Key : 120
Console#
