Installation MACH104
Release
07
07/2014
29
5 Deinstallation
5.1 Removing the device
Disconnect the data cables.
Disable the working voltage.
Disconnect the operating voltage.
Remove the power connector from the device.
To detach the device from the switch cabinet or the wall, remove the
screws from the brackets on the device.
Figure 16: Disassembling the device
5.2 Removing the SFP transceivers
Pull the SFP transceiver out of the socket by means of the opened lock.
Close the socket with the protective cap.
Figure 17: Deinstalling an SFP transceiver
