32
Installation MACH104
Release 07 07/2014
 Network range
Note: The line lengths specified for the transceivers apply for the respec-
tive fiber data (fiber attenuation and BLP/dispersion).
IEC/EN 61000-4-6 Conducted disturbances
150 kHz ... 80 MHz 10 V
EN 61000-4-9 Pulse magnetic fields 300 A/m
EMC interference
emission
EN 55022 Class A Yes
FCC 47 CFR Part 15 Class A Yes
10/100/1000 Mbit/s twisted pair port
Length of a twisted pair segment max. 100 m (for cat5e cable)
Product
code
M-FAST-
SFP-...
Wave
length
Fiber System
attenua-
tion
Example
for F/O line
length
a
a. including 3 dB system reserve when compliance with the fiber data is observed
Fiber atten-
uation
BLP/
dispersion
-MM/LC... MM 1310 nm 50/125 µm 0-8 dB 0-5 km 1.0 dB/km 800 MHz×km
-MM/LC... MM 1310 nm 62.5/125 µm 0-11 dB 0-4 km 1.0 dB/km 500 MHz×km
-SM/LC... SM 1310 nm 9/125 µm 0-13 dB 0-25 km 0.4 dB/km 3.5
ps/(nm×km)
-
SM+/LC...
SM 1310 nm 9/125 µm 10-29 dB 25-65 km 0.4 dB/km 3.5
ps/(nm×km)
-LH/LC... SM 1550 nm 9/125 µm 10-29 dB 47-104 km 0.25 dB/km 19 ps/(nm×km)
-LH/LC... SM 1550 nm 9/125 µm 10-29 dB 55-140 km 0.18 dB/km
b
b. with ultra-low-loss optical fiber
18 ps/(nm×km)
Table 4: Fiber port 100BASE-FX (SFP fiber optic Fast Ethernet Transceiver)
Product
code
M-SFP-...
Wave
length
Fiber System
attenua-
tion
Example
for F/O line
length
a
Fiber
attenua-
tion
BLP
b
/
dispersion
-SX/LC... MM 850 nm 50/125 µm 0-7.5 dB 0-550 m 3.0 dB/km 400 MHz×km
-SX/LC... MM 850 nm 62.5/125 µm 0-7.5 dB 0-275 m 3.2 dB/km 200 MHz×km
-MX/LC MM 1310 nm 50/125 µm 0-8 dB 2 km
c
1.0 dB/km 500 MHz×km
-MX/LC MM 1310 nm 62.5/125 µm 0-8 dB 1 km 1.0 dB/km 500 MHz×km
-LX/LC... MM 1310 nm
d
50/125 µm 0-10.5 dB 0-550 m 1.0 dB/km 800 MHz×km
-LX/LC... MM 1310 nm
d
62.5/125 µm 0-10.5 dB 0-550 m 1.0 dB/km 500 MHz×km
-LX/LC... SM 1310 nm 9/125 µm 0-10.5 dB 0-20 km
e
0.4 dB/km 3.5
ps/(nm×km)
Table 5: Fiber port 1000BASE-FX (SFP fiber optic Gigabit Ethernet Transceiver)
EMC interference immunity
