Installation MACH104
Release 07 07/2014
35
Gigabit Ethernet SFP transceiver Order number
M-SFP-TX/RJ45 943 977-001
Note the following for the M-SFP-TX/RJ45 transceiver:
 Can be used with:
- HiOS from software version 03.0.00
- Classic Switch Software from software version 04.1.00
- HiSecOS from software version 01.2.00
Not for use with the following devices:
- SPIDER II
- MSP/MSM
- EES
 Twisted pair ports that are implemented using this transceiver have increased link failure
detection times compared to twisted pair ports that are directly available in the device.
 When using this SFP transceiver, expect increased switching times with the RSTP.
 Cannot be used in combo ports.
M-SFP-SX/LC 943 014-001
M-SFP-SX/LC EEC 943 896-001
M-SFP-MX/LC EEC 942 108-001
M-SFP-LX/LC 943 015-001
M-SFP-LX/LC EEC 943 897-001
M-SFP-LX+/LC 942 023-001
M-SFP-LX+/ LC EEC 942 024-001
M-SFP-LH/LC 943 042-001
M-SFP-LH/LC EEC 943 898-001
M-SFP-LH+/LC 943 049-001
Fast Ethernet SFP transceiver Order number
M-FAST SFP-TX/RJ45 942 098-001
M-FAST SFP-TX/RJ45 EEC 942 098-002
Note the following for the M-FAST SFP-TX... transceiver:
 Can be used with:
- HiOS from software version 03.0.00
- On the PRP ports of the RSP devices starting with software version 02.0.01
- On the PRP ports of the EES devices starting with software version 02.0.02
- Classic Switch Software from software version 08.0.00
- HiSecOS ab Software-Version 01.2.00
 Twisted-pair ports realized through this transceiver have longer link failure detection times
compared with twisted-pair ports provided by the device directly.
 When using these SFP transceivers, assume a higher switching time for RSTP.
 Not applicable for combo ports.
M-FAST SFP-MM/LC 943 865-001
M-FAST SFP-MM/LC EEC 943 945-001
M-FAST SFP-SM/LC 943 866-001
M-FAST SFP-SM/LC EEC 943 946-001
M-FAST SFP-SM+/LC 943 867-001
M-FAST SFP-SM+/LC EEC 943 947-001
M-FAST SFP-LH/LC 943 868-001
M-FAST SFP-LH/LC EEC 943 948-001
Bidirectional Gigabit Ethernet SFP transceiver Order number
M-SFP-BIDI Type A LX/LC EEC 943 974-001
M-SFP-BIDI Type B LX/LC EEC 943 974-002
M-SFP-BIDI Type A LH/LC EEC 943 975-001
