18
Installation MACH1040
Release
05
03/2021
The device provides you with a large range of functions, which the manuals
for the operating software inform you about. You can download these
manuals as PDF files from the Internet on the Hirschmann product pages
(http://www.doc.hirschmann.com).
The Hirschmann network components help you ensure continuous
communication across all levels of the company.
1.2 Combination options
The product designation of your device is made from combining the desired
product characteristics in accordance with the following table. The
corresponding short designation is in column 3.
You have numerous options of combining the device characteristics. You can
determine the possible combinations using the configurator which is
available in the Belden Online Catalog https://catalog.belden.com on the web
page of the device.
Position Characteristic Designation Property
1 ... 7 Product MAR1040 MACH Ruggedized Gigabit Ethernet Switch
MAR1042 MACH Ruggedized Gigabit Ethernet Switch with
PoE
MAR1140 MACH Ruggedized Gigabit Ethernet Switch,
ports on the rear
MAR1142 MACH Ruggedized Gigabit Ethernet Switch,
ports on the rear and with PoE
8 - (hyphen) -
9 ... 10 10/100/1000 Mbit/s
port 1 ... 4
4C 4 × Combo port (SFP slot: 100/1000 Mbit/s,
alternatively twisted pair RJ45 socket: 10/100/
1000 Mbit/s)
11 ... 12 10/100/1000 Mbit/s
port 5 ... 8
4C See 9 ... 10
13 ... 14 10/100/1000 Mbit/s
port 9 ... 10
4C See 9 ... 10
15 ... 16 10/100/1000 Mbit/s
port 13 ... 16
4C See 9 ... 10
17 ... 18 Port 17 ... 20 99 Not present
19 ... 20 Port 21 ... 24 99 Not present
21 Temperature range S Standard: 0 °C ... +60 °C (+32 °F ... +140 °F)
T Extended: -40 °C ... +70 °C (-40 °F ... +158 °F)
E Extended: -40 °C ... +70 °C (-40 °F ... +158 °F),
Conformal Coating
22 Supply voltage
range, power supply
unit 1
L See “General technical data” on page 45.
M
Table 1: Combination options of the MACH1040 device variants
