Hirschmann MACH1040 User Manual

Installation MACH1040
Release 05 03/2021
45
7 Technical data
7.1 General technical data
Dimensions W ×
H× D
MAR1... 448 mm × 345 mm × 44 mm (17.64 in
× 13.58 in × 1.73 in) (without brackets)
463 mm × 345 mm × 44 mm (18.23 in
× 13.58 in × 1.73 in) (with brackets)
Weight MAR1040..., MAR1140... max. 4.2 kg (9.3 lb)
MAR1040..., MAR1140... devices
with redundant power supply unit
max. 4.4 kg (9.7 lb)
MAR1042..., MAR1142... devices
with PoE power supply unit
max. 4.6 kg (10.2 lb)
Power supply
Characteristic
value M
Rated voltage range 100 V AC ... 240 V AC, 50 Hz ... 60 Hz
Voltage range including maximum
tolerances
90 V AC ... 265 V AC, 47 Hz ... 63 Hz
Rated voltage range 110 V DC ... 250 V DC
Voltage range including maximum
tolerances
77 V DC ... 300 V DC
Connection type 3-pin terminal block
Power loss buffer >20 ms at 230 V AC
Back-up fuse Nominal rating: 2.5 A
Characteristic: slow blow
Peak inrush current 14 A
Power supply
Characteristic
value L
Rated voltage range 24 V DC ... 48 V DC
Voltage range including maximum
tolerances
18 V DC ... 60 V DC
Connection type 3-pin terminal block
Power loss buffer >10 ms at 20.4 V DC
Back-up fuse Nominal rating: 6.3 A
Characteristic: slow blow
Peak inrush current 15 A
Signal contact
(non-hazardous
locations)
Nominal value I
max
=2A at U
max
= 230 V AC
I
max
=2A at U
max
=30VDC
I
max
= 0.2 A at U
max
= 125 V DC
I
max
= 0.1 A at U
max
= 250 V DC
Connection type 2-pin terminal block
Signal contact
(Hazardous
Locations Class 1,
Division 2)
Electrical parameters V
max
= 30 V
max
= 90 mA
C
i
= 50 pF
L
i
= 2 μH
See “Use in Hazardous Locations” on
page 11.
Connection type 2-pin terminal block
