7.3 EMC and immunity
EMC interference
immunity
IEC/EN 61850-3 EMI
TYPE test, test
according to
Description Test level
IEC/EN 61000-4-2 Electrostatic discharge
Contact discharge ±8 kV
Air discharge ±15 kV
IEC/EN 61000-4-3 Electromagnetic field
80 MHz ... 2700 MHz 20 V/m
IEC/EN 61000-4-4 Fast transients (burst)
DC Power Line ±4 kV
AC Power Line ±4 kV
Data line ±4 kV
IEC/EN 61000-4-5 Voltage surges
DC Power Line ±2 kV line/ground; ±1 kV line/line
AC Power Line ±4 kV line/ground; ±2 kV line/line
Data line ±4 kV line/ground
IEC/EN 61000-4-6 Conducted disturbances
150 kHz ... 80 MHz 10 V
IEC/EN 61000-4-12 Damped oscillation
DC Power Line ±2,5 kV line/earth; ±1 kV line/line
AC Power Line ±2,5 kV line/earth; ±1 kV line/line
Data line ±2,5 kV line/earth; ±1 kV line/line
IEC 60255-5 dielectric strength
DC power line - Power supply unit
supply voltage characteristic
value L
500 V AC
500 V AC
AC power line - Power supply unit
supply voltage characteristic
value M
2000 V AC
2000 V AC
DC power line - Power supply unit
supply voltage characteristic
value M
2000 V AC
Signal contact supply voltage
characteristic value L and M
2000 V AC
EMC interference
immunity
IEEE 1613 EMI
TYPE test, test
according to
Description Test level
IEEE C37.90.3 Electrostatic discharge
Contact discharge ±8 kV
Air discharge ±15 kV
IEEE C37.90.2 Electromagnetic field
80 MHz ... 1000 MHz 35 V/m (peak)
