38
Installation MACH1040
Release
05
03/2021
2.4.2 Vertical mounting on the wall
Move the two pre-installed mounting brackets into the position shown
below.
Additionally attach 2 brackets to the back of the device.
You obtain the additional brackets as accessories.
See “Accessories” on page 57.
Fasten the device by screwing the brackets to the wall.
2.4.3 Grounding the device
The device is grounded via the separate grounding screw on the back of the
device.
WARNING
FIRE HAZARD
Install the device in a fire enclosure according to IEC/EN 62368-1 if you
install the device vertically.
Failure to follow these instructions can result in death, serious injury,
or equipment damage.
