Installation MACH1040
Release
05
03/2021
57
7.7 Order numbers/product description
Combination options and device names (see table 1).
You can also order the following device variants using their order numbers:
7.8 Accessories
Note that products recommended as accessories may have different
characteristics to those of the device, which may limit the application range
of the overall system. For example, if you add an accessory with IP20 to a
device with IP65, the degree of protection of the overall system is reduced to
IP20.
Name Description Order number
MAR1040-
4C4C4C4C9999SM9H
PHH
MACH 1040 device with
- 16 x Gigabit Ethernet combo ports
- ports on front of device,
power supply connection on back of device
- standard temperature range
- 1 power unit type M
- Layer2 Professional software
942 004 - 001
Fast Ethernet SFP transceiver Order number
M-FAST SFP-TX/RJ45 942 098-001
M-FAST SFP-TX/RJ45 EEC 942 098-002
The following operating conditions apply to twisted pair transceivers:
Usable with:
- HiOS as of software version 03.0.00
- for PRP ports on RSP devices, as of software version 02.0.01
- for PRP ports on EES devices, as of software version 02.0.02
- Classic switch software as of software version 08.0.00
- HiSecOS as of software version 01.2.00
Longer RSTP switching times and link loss detection times compared to twisted pair ports
provided by the device directly.
Not applicable for combo ports.
Not applicable for ports which support only Gigabit Ethernet.
It is currently not possible to set autocrossing manually.
M-FAST SFP-MM/LC 943 865-001
M-FAST SFP-MM/LC EEC 943 945-001
M-FAST SFP-SM/LC 943 866-001
M-FAST SFP-SM/LC EEC 943 946-001
M-FAST SFP-SM+/LC 943 867-001
M-FAST SFP-SM+/LC EEC 943 947-001
M-FAST SFP-LH/LC 943 868-001
M-FAST SFP-LH/LC EEC 943 948-001
SFP-FAST-MM/LC
a
942 194-001
SFP-FAST-MM/LC EEC
a
942 194-002
Table 17: Accessory: Fast Ethernet SFP transceiver
