Hirschmann MACH1040 User Manual

50
Installation MACH1040
Release 05 03/2021
IEEE C37.90.1 Fast transients (burst)
DC Power Line ±4 kV
AC Power Line ±4 kV
Data line ±4 kV
IEEE C37.90.1 Damped oscillation
DC Power Line ±2,5 kV line/earth; ±1 kV line/line
AC Power Line ±2,5 kV line/earth; ±1 kV line/line
Data line ±2,5 kV line/earth; ±1 kV line/line
IEEE C37.90 H.V. Impulse
DC Power Line ± 5 kV line/earth
AC Power Line ± 5 kV line/earth
IEEE C37.90 dielectric strength
DC power line - Power supply unit
supply voltage characteristic
value L
500 V AC
AC power line - Power supply unit
supply voltage characteristic
value M
2000 V AC
DC power line - Power supply unit
supply voltage characteristic
value M
2000 V AC
Signal contact supply voltage
characteristic value L and M
2000 V AC
EMC interference
emission
EN 55032 Class A
FCC 47 CFR Part 15 Class A
German Lloyd Classification + Construction Guidelines VI-7-3 Part 1 Ed. 2001
Environment
TYPE test, test
according to
Description Test level
IEC 60068-2-1
IEC 60068-2-2
IEC 60068-2-30
IEC 60068-2-6
IEC 60068-2-27
Cold
Dry heat
Relative humidity
Vibration, test Fc
Shock, test Ea
−40 °F (−40 °C), 16 hours
+185 °F (+85 °C), 16 hours
95 % (non condensing)
131 °F (55 °C), 4 cycles
2 - 9 Hz with 3 mm amplitude
1 g at 9 - 150 Hz
1.5 g at 200 - 500 Hz
15 g at 11 ms
EMC interference
immunity
IEEE 1613 EMI
TYPE test, test
according to
Description Test level
