Installation MSP30/32/40/42 and MSM20/22/24/40/42/46/50
Release
12
06/2018
21
11 Number:
10
a
/100/1000/10000
Mbit/s ports
00 ×
12 Temperature range S Standard +32 °F ... +140 °F (0 °C ...
+60 °C)
T Extended 40 °F ... +158 °F (40 °C ...
+70 °C)
under UL conditions: max.
+140 °F (+60 °C)
E Extended with
Conformal Coating
40 °F ... +158 °F (40 °C ...
+70 °C)
under UL conditions: max.
+140 °F (+60 °C)
13 Supply voltage C 2 voltage inputs for redundant power
supply
Rated voltage range
24 V DC ... 48 V DC
P PoE 2 voltage inputs for redundant power
supply
Rated voltage range
45 V DC ... 57 V DC
PoE+ 2 voltage inputs for redundant power
supply
Rated voltage range
51 V DC ... 57 V DC
14 ... 15 Certificates and
declarations
Note: You will find detailed information on the certificates and
declarations applying to your device in a separate overview.
See table 3 on page 24.
16 ... 17 Software packages 99 Reserved
UR Unicast Routing
MR Unicast + Multicast Routing
18 ... 19 Customer-specific
version
HH Hirschmann standard
HX Hirschmann Extreme Conditions
20 Software configuration E Entry (Hirschmann Standard)
B Diagnostic User (DBDEW)
I Ethernet/IP
PProfinet
21 ... 22 Software level 2A HiOS Layer 2 Advanced
3A HiOS Layer 3 Advanced
23 ... 27 Software version 06.0. Software version 06.0
XX.X Current software version
a. Only for twisted pair connections
Item Characteristic Characteri
stic value
Description
Table 1: Device name and product code
