Hirschmann MSP30 User Manual

22
Installation MSP30/32/40/42 and MSM20/22/24/40/42/46/50
Release 12 06/2018
 Media modules
Item Characteristic Characteristic
value
Description
1 ... 3 Product MSM MICE Switch Media Module
4Data rate2 10
a
/100 Mbit/s ports
410
a
/100/1000 Mbit/s ports
5 1000/2500 Mbit/s ports
5 Hardware type 0 Standard
2 Suitable for PoE or PoE+
4 Suitable for I/O operation
6 suitable for PoE or PoE+ with external power supply
6 (hyphen) -
7 ... 8 Port 1 T1 Twisted Pair (TX) RJ45 socket
T5 Twisted Pair (TX) M12 socket
M2 Multimode FX DSC (100 Mbit/s only)
M4 Multimode FX ST (100 Mbit/s only)
S2 Singlemode FX DSC (100 Mbit/s only)
S4 Singlemode FX ST (100 Mbit/s only)
L2 Singlemode Long Haul
FX DSC
(100 Mbit/s only)
G2 Singlemode Long Haul
FX DSC 200 km
(100 Mbit/s only)
C1 Combo port:
Twisted Pair (TX)
F/O
RJ45 socket
SFP slot
IO Digital Input/Output
Q6 SFP slot 1000/2500 Mbit/s
99 Not present
9 ... 10 Port 2 See items 7 ... 8
11 ... 12 Port 3 See items 7 ... 8
13 ... 14 Port 4 See items 7 ... 8
15 Temperature
range
S Standard +32 °F ... +140 °F (0 °C ...
+60 °C)
T Extended −40 °F ... +158 °F (−40 °C
... +70 °C)
under UL conditions: max.
+140 °F (+60 °C)
E Extended with
Conformal Coating
−40 °F ... +158 °F (−40 °C
... +70 °C)
under UL conditions: max.
+140 °F (+60 °C)
16 ... 17 Certificates and
declarations
You will find detailed information on the certificates and declarations
applying to your device in a separate overview.
See table 4 on page 25.
18 ... 19 Customer-
specific version
HH Hirschmann standard
HX Hirschmann Extreme Conditions
20 Hardware
configuration
9none
Table 2: Device name and product code
