Installation MSP30/32/40/42 and MSM20/22/24/40/42/46/50
Release
12
06/2018
29
View from above
Note: On the basic device MSP40/42, the media module slot 1 is coded
differently from the other slots. Only MSM50 media modules can be
installed on this media module slot.
1 Slot for the SD card
2Thumb screw
3 Backplane (Basic device MSP30/32/40/42)
4 Power module (Basic device MSP30/32/40/42)
5 Slot 1 for media modules
6 Slot 2 for media modules
7 Slot 3 for media modules
8 Female
multipoint
connector
Table 8: View from above (using the example MSP30/32-0804.......HH...)
