8.2 Digital input
Note: For the pin assignment see “Digital input” on page 50.
8.3 Digital output
Tightening torque 2-pin terminal block 3 lb-in (0.34 Nm)
3-pin terminal block 4.4 lb-in (0.5 Nm)
8-pin terminal block 3 lb-in (0.34 Nm)
12-pin terminal block 3 lb-in (0.34 Nm)
4-pin M12 connector 5.3 lb-in (0.6 Nm)
Installation on the
backplane with screws
Device variants with
characteristic value HH/HX
2.65 lb-in (0.3 Nm)
Installation on the
backplane with clamping
jaws and M4 screws
Device variants with
characteristic value HX
17.7 lb-in (2 Nm)
a. xx = M2, M4, S2, S4, L2, G2
b. Temperature of the ambient air at a distance of 2 in (5 cm) from the device
c. Hirschmann recommends to use SFP transceivers with “EEC” extension.
d. Use SFP transceivers with the “EEC” extension only, otherwise the standard temperature
range applies.
Maximum permitted input voltage range −32 V DC … +32 V DC
Nominal input voltage +24 V DC
Input voltage, low level, status “0” −0.3 V DC ... +5.0 V DC
Input voltage, high level, status “1” +11 V DC … +30 V DC
Maximum input current at 24 V input voltage 15 mA
Input characteristic according to IEC 61131-2 (current-
consuming)
Type 3
Connection type 8-pin terminal block
Maximum permitted supply voltage max. 60 V DC or max. 30 V AC, SELV
under UL conditions: max. 30 V DC,
ohmic load
Maximum current load of relay contacts and terminals 1 A
Maximum switching frequency 1 Hz
Relay type Changeover
Contact voltage isolated
Protective circuit of relay contacts No
