Hirschmann MSP30

74
Installation MSP30/32/40/42 and MSM20/22/24/40/42/46/50
Release 12 06/2018
 Media modules
Dimensions
W × H × D
MSM20
MSM22
MSM24
MSM40
MSM42
MSM46
MSM50
1.50 in. × 5.24 in. × 4.65 in. (38 mm ×
133 mm × 118 mm)
Weight
a
MSM20-xxT1T1T1... 0.44 lb (199 g
MSM20-xxxxT1T1... 0.45 lb (201 g)
MSM20-xxxxxxxx... 8.78 oz (249 g)
MSM20-T5T5T5T5...HH 7.76 oz (220 g)
MSM20-T5T5T5T5...HX 8.61 oz (244 g)
MSM22-T5T5T5T5... 7.97 oz (226 g)
MSM24-IOIOIOIO... 8.85 oz (251 g)
MSM40-T1T1T1T1... 6.81 oz (193 g)
MSM40-C1C1C1C1... 7.55 oz (214 g)
without SFP transceiver
MSM42-T1T1T1T1... 7.13 oz (202 g)
MSM46-T1T1T1T1... 7.94 oz (225 g)
MSM50-Q6Q6Q6Q6... 6.88 oz (195 g)
without SFP transceiver
Climatic conditions during
operation
Ambient air temperature
b
. Devices with operating temperature
characteristic value S (standard):
+32 °F ... +140 °F (0 °C ... +60 °C)
c
Devices with operating temperature
characteristic value E and T
(extended):
−40 °F ... +158 °F (−40 °C ... +70 °C)
d
under UL conditions: max. +140 °F
(+60 °C)
Humidity 5 % ... 95 %
(non-condensing)
Air pressure min. 700 hPa (+9842 ft; +3000 m)
max. 1060 hPa (−1312 ft; −400 m)
Climatic conditions during
storage
Ambient air temperature
b
−40 °F ... +185 °F (−40 °C ... +85 °C)
Humidity 5 % ... 95 %
(non-condensing)
Air pressure min. 700 hPa (+9842 ft; +3000 m)
max. 1060 hPa (−1312 ft; −400 m)
Pollution degree 2
Protection classes Laser protection Class 1 in compliance with IEC 60825-1
Degree of protection IP20
