Hirschmann MSP30

Installation MSP30/32/40/42 and MSM20/22/24/40/42/46/50
Release 12 06/2018
73
Supply voltage with
the characteristic
value P
Rated voltage Device variants with PoE: 48 V DC
Device variants with PoE
Plus:
54 V DC
Voltage range incl. maximum
tolerances
Device variants with PoE: 45 V DC ...
57 V DC
Device variants with PoE
Plus:
51 V DC ...
57 V DC
Max. PoE power 124 W
a
Connection type 4-pin terminal block
max. conductor cross section AWG12
(2.5 mm²)
Power loss buffer > 10 ms at 20.4 V DC
(only applies to the basic device)
Overload current protection at
input
Non-replaceable fuse
Back-up fuse Nominal rating: 6.3 A
Characteristic: slow blow
Peak inrush current < 5 A
Climatic conditions
during operation
Ambient air temperature
b
. Devices with operating temperature
characteristic value S (standard):
+32 °F ... +140 °F (0 °C ... +60 °C)
c
Devices with operating temperature
characteristic value E and T (extended):
−40 °F ... +158 °F (−40 °C ... +70 °C)
d
under UL conditions: max. +140 °F
(+60 °C)
Humidity 5 % ... 95 %
(non-condensing)
Air pressure min. 700 hPa (+9842 ft; +3000 m)
max. 1060 hPa (−1312 ft; −400 m)
Climatic conditions
during storage
Ambient air temperature
a
−40 °F ... +185 °F (−40 °C ... +85 °C)
Humidity 5 % ... 95 %
(non-condensing)
Air pressure min. 700 hPa (+9842 ft; +3000 m)
max. 1060 hPa (−1312 ft; −400 m)
Signal contact
“FAULT”
Switching current max. 1 A, SELV
Switching voltage max. 60 V DC or max. 30 V AC, SELV
under UL conditions: max. 30 V DC,
resistive load
Pollution degree 2
Protection classes Laser protection Class 1 in compliance with IEC 60825-1
Degree of protection IP20
Tightening torque 4-pin terminal block 4.4 lb-in (0.5 Nm)
Grounding screw 4.4 lb-in (0.5 Nm)
a. The MSP basic devices MSP32 and MSP42 support a PoE power budget of 120 W. You
cannot expand the PoE power budget of the basic devices with media modules.
b. Temperature of the ambient air at a distance of 2 in (5 cm) from the device
c. Hirschmann recommends to use SFP transceivers with “EEC” extension.
d. Use SFP transceivers with the “EEC” extension only, otherwise the standard temperature
range applies.
