Hirschmann MSP30 User Manual

72
Installation MSP30/32/40/42 and MSM20/22/24/40/42/46/50
Release 12 06/2018
8 Technical data
8.1 General technical data
 Basic device
Dimensions
W × H × D
MSP30/32-0804.......HH... 9.33 in. × 5.83 in. × 5.59 in. (237 mm ×
148 mm × 142 mm)
MSP40/42-0012.......HH...
MSP30/32-1604.......HH... 12.36 in. × 5.83 in. × 5.59 in. (314 mm ×
148 mm × 142 mm)
MSP40/42-0020.......HH...
MSP30/32-2404.......HH... 15.39 in. × 5.83 in. × 5.59 in. (391 mm ×
148 mm × 142 mm)
MSP40/42-0028.......HH...
MSP30-0804.......HX... 10.91 in. × 6.81 in. × 5.51 in. (277 mm ×
173 mm × 140 mm)
MSP30-1604.......HX... 13.94 in. × 6.81 in. × 5.51 in. (354 mm ×
173 mm × 140 mm)
MSP30-2404.......HX... 16.97 in. × 6.81 in. × 5.51 in. (431 mm ×
173 mm × 140 mm)
Weight MSP30-0804.......HH... 4.6 lb (2.1 kg)
MSP40-0012.......HH...
MSP32-0804.......HH... 4.6 lb (2.2 kg)
MSP42-0012.......HH...
MSP30-1604.......HH... 5.3 lb (2.4 kg)
MSP40-0020.......HH...
MSP32-1604.......HH... 5.5 lb (2.5 kg)
MSP42-0020.......HH...
MSP30-2404.......HH... 5.9 lb (2.65 kg)
MSP40-0028.......HH...
MSP32-2404.......HH... 6.1 lb (2.75 kg)
MSP42-0028.......HH...
MSP30-0804.......HX... 6.83 lb (3.1 kg)
MSP30-1604.......HX... 7.93 lb (3.6 kg)
MSP30-2404.......HX... 8.81 lb (4.0 kg)
Supply voltage with
the characteristic
value C
Rated voltage range 24 V DC ... 48 V DC
Voltage range incl. maximum
tolerances
18VDC... 60VDC
Connection type 4-pin terminal block
max. conductor cross section AWG12
(2.5 mm²)
Power loss buffer > 10 ms at 20.4 V DC
(only applies to the basic device)
Overload current protection at
input
Non-replaceable fuse
Back-up fuse Nominal rating: 6.3 A
Characteristic: slow blow
Peak inrush current < 5 A
