Hirschmann MSP30

Installation MSP30/32/40/42 and MSM20/22/24/40/42/46/50 Release
12
06/2018
87
-LX+/LC... SM 1310 nm 9/125 µm 5 dB ... 20 dB 8.70 mi ... 26.10 mi
(14 km ... 42 km)
0.4 dB/km 3.5 ps/(nm×km)
-LH/LC... LH 1550 nm 9/125 µm 5 dB ... 22 dB 14.29 mi ... 49.71 mi
(23 km ... 80 km)
0.25 dB/km 19 ps/(nm×km)
-LH+/LC LH 1550 nm 9/125 µm 15 dB ... 30 dB 44.12 mi ... 67.11 mi
(71 km ... 108 km)
0.25 dB/km 19 ps/(nm×km)
-LH+/LC LH 1550 nm 9/125 µm 15 dB ... 30 dB 44.12 mi ... 79.54 mi
(71 km ... 128 km)
0.21 dB/km
(typically)
19 ps/(nm×km)
a. MM = Multimode, SM = Singlemode, LH = Singlemode Longhaul
b. Including 3 dB system reserve when compliance with the fiber data is observed.
c. Using the bandwidth-length product is inappropriate for expansion calculations.
d. Distances of up to 1.86 mi (3 km) can be reached, 1000 MHz×km (1300 nm)
e. With F/O adapter compliant with IEEE 802.3-2002 Clause 38 (single-mode fiber offset-launch mode conditioning patch cord).
f. With F/O adapter compliant with IEEE 802.3-2002 Clause 38 (single-mode fiber offset-launch mode conditioning patch cord).
g. Including 2.5 dB system reserve when compliance with the fiber data is observed.
Product code
M-SFP-BIDI...
Mode
a
a. MM = Multimode, SM = Singlemode, LH = Singlemode Longhaul
Wave length
TX
Wave length
RX
Fiber System
attenuation
Example for F/O
cable length
b
b. Including 3 dB system reserve when compliance with the fiber data is observed.
Fiber attenuation Dispersion
Type A LX/LC EEC SM 1310 nm 1550 nm 9/125 µm 0 dB ... 11 dB 0 km ... 12.43 mi
(0 km ... 20 km)
0.4 dB/km 3.5 ps/(nm×km)
Type B LX/LC EEC SM 1550 nm 1310 nm 9/125 µm 0 dB ... 11 dB 0 mi ... 12.43 mi
(0 km ... 20 km)
0.25 dB/km 19 ps/(nm×km)
Type A LH/LC EEC LH 1490 nm 1590 nm 9/125 µm 5 dB ... 24 dB 14.29 mi ... 49.71 mi
(23 km ... 80 km)
0.25 dB/km 19 ps/(nm×km)
Type B LH/LC EEC LH 1590 nm 1490 nm 9/125 µm 5 dB ... 24 dB 14.29 mi ... 49.71 mi
(23 km ... 80 km)
0.25 dB/km 19 ps/(nm×km)
Table 47: F/O port (bidirectional Gigabit Ethernet SFP Transceiver)
Product code
M-SFP-...
Mode
a
Wave length Fiber System
attenuation
Example for F/O
cable length
b
Fiber attenuation BLP
c
/Dispersion
Table 46: Fiber port 1000BASE-FX (SFP fiber optic Gigabit Ethernet Transceiver)
