Hirschmann MSP30

86
Installation MSP30/32/40/42 and MSM20/22/24/40/42/46/50
Release
12
06/2018
8.9 Network range
Note: The line lengths specified for the transceivers apply for the respective fiber data (fiber attenuation and BLP/
dispersion).
Media modules Maximum power output
MSM22 62 W
MSM42 62 W
MSM46 124 W
Table 45: Maximum PoE power output
Product code
M-SFP-...
Mode
a
Wave length Fiber System
attenuation
Example for F/O
cable length
b
Fiber attenuation BLP
c
/Dispersion
-SX/LC... MM 850 nm 50/125 µm 0 dB ... 7.5 dB 0 mi ... 0.34 mi
(0 km ... 0.55 km)
3.0 dB/km 400 MHz×km
-SX/LC... MM 850 nm 62.5/125 µm 0 dB ... 7.5 dB 0 mi ... 0.17 mi
(0 km ... 0.275 km)
3.2 dB/km 200 MHz×km
-MX/LC MM 1310 nm 50/125 µm 0 dB ... 8 dB 1.24 mi (2 km)
d
1.0 dB/km 500 MHz×km
-MX/LC MM 1310 nm 62.5/125 µm 0 dB ... 8 dB 0.62 mi (1 km) 1.0 dB/km 500 MHz×km
-LX/LC... MM 1310 nm
e
50/125 µm 0 dB ... 10.5 dB 0 mi ... 0.34 mi
(0 km ... 0.55 km)
1.0 dB/km 800 MHz×km
-LX/LC... MM 1310 nm
f
62.5/125 µm 0 dB ... 10.5 dB 0 mi ... 0.34 mi
(0 km ... 0.55 km)
1.0 dB/km 500 MHz×km
-LX/LC... SM 1310 nm 9/125 µm 0 dB ... 10.5 dB 0 mi ... 12.43 mi
(0 km ... 20 km)
g
0.4 dB/km 3.5 ps/(nm×km)
Table 46: Fiber port 1000BASE-FX (SFP fiber optic Gigabit Ethernet Transceiver)
