8.8 Power consumption/power output
The order numbers correspond to the product codes of the devices.
See “Device name and product code” on page 20.
Device name Maximum power consumption Power output
MSP30-0804... 16.0 W 55.0 Btu (IT)/h
MSP30-1604... 17.0 W 58.0 Btu (IT)/h
MSP30-2404... 18.0 W 61.0 Btu (IT)/h
MSP32-0804... 17.0 W 58.0 Btu (IT)/h
MSP32-1604... 18.0 W 61.0 Btu (IT)/h
MSP32-2404... 19.0 W 65.0 Btu (IT)/h
MSP40-0012... 17.0 W 58.0 Btu (IT)/h
MSP40-0020... 19.0 W 65.0 Btu (IT)/h
MSP40-0028... 21.5 W 73.0 Btu (IT)/h
MSP42-0012... 18.0 W 61.0 Btu (IT)/h
MSP42-0020... 19.5 W 67.0 Btu (IT)/h
MSP42-0028... 22.5 W 77.0 Btu (IT)/h
Module
a
a. xx = M2, M4, S2, S4, L2, G2
Slot
b
b. FE= Fast Ethernet 100 MBit/s; GE= Gigabit Ethernet 1000 MBit/s
Maximum power
consumption
Power output
MSM20 media modules:
MSM20-xxT1T1T1... GE 5.0 W 17.0 Btu (IT)/h
MSM20-xxT1T1T1... FE 4.0 W 14.0 Btu (IT)/h
MSM20-xxxxT1T1... GE 4.0 W 14.0 Btu (IT)/h
MSM20-xxxxT1T1... FE 4.0 W 14.0 Btu (IT)/h
MSM20-xxxxxxxx... GE 5.0 W 17.0 Btu (IT)/h
MSM20-xxxxxxxx... FE 5.0 W 17.0 Btu (IT)/h
MSM20-T5T5T5T5... FE 2.0 W 7.0 Btu (IT)/h
MSM22-T5T5T5T5... FE 3.0 W 10.0 Btu (IT)/h
MSM24 media modules:
MSM24-IOIOIOIO... — 7.0 W 24.0 Btu (IT)/h
MSM40 media modules:
MSM40-C1C1C1C1... GE 5.0 W 17.0 Btu (IT)/h
MSM40-C1C1C1C1... FE 5.0 W 17.0 Btu (IT)/h
MSM40-T1T1T1T1... GE 3.0 W 10.0 Btu (IT)/h
MSM40-T1T1T1T1... FE 2.0 W 7.0 Btu (IT)/h
MSM42 media modules:
MSM42-T1T1T1T1... GE 4.0 W 14.0 Btu (IT)/h
MSM42-T1T1T1T1... FE 3.0 W 10.0 Btu (IT)/h
MSM46 media modules:
MSM46-T1T1T1T1... GE 4.0 W 14.0 Btu (IT)/h
MSM46-T1T1T1T1... FE 3.0 W 10.0 Btu (IT)/h
MSM50 media modules:
MSM50-Q6Q6Q6Q6... GE 3.0 W 10.0 Btu (IT)/h
MSM50-Q6Q6Q6Q6... 2.5 GE 4.0 W 14.0 Btu (IT)/h
Table 44: Overview: Power consumption and power output
