9 Scope of delivery, order numbers and
accessories
9.1 Scope of delivery
 Basic device
 Media modules
9.2 Accessories
Number Article
1 × Device (backplane and power module)
1 × General safety instructions
1 × 4-pin terminal block for digital input
2 × 4-pin terminal block for supply voltage
Numbe
r
Article
1 × Device
1 × General safety instructions
2 × Only with the
customer-specific
version with
characteristic value
HX
Hardware elements with screws M4 × 12
1 × Only with media
module MSM24
2-pin terminal block for 24 V DC auxiliary voltage
8-pin terminal block for digital input
12-pin terminal block for digital output
1 × Only with media
module MSM46
3-pin terminal block for external PoE power supply
Designation Order number
AutoConfiguration Adapter ACA21-USB (EEC)
a
943 271-003
AutoConfiguration Adapter ACA22-USB (EEC) 942 124-001
AutoConfiguration Adapter ACA31 942 074-001
Network management software Industrial HiVision 943 156-xxx
Terminal cable: RJ45 on USB 942 096-001
Terminal cable: RJ45 on Sub-D, 9-pin 942 097-001
RPS 90/48V HV (high-voltage) PoE power unit 943 979-001
RPS 90/48V LV (low-voltage) PoE power unit 943 980-001
