a. The AutoConfiguration Adapter ACA21-USB (EEC) is only compatible with MSP30/32 basic
devices.
2.5 Gigabit Ethernet SFP transceiver Order number
M-SFP-2.5-MM/LC EEC 942 162-001
M-SFP-2.5-SM-/LC EEC 942 163-001
M-SFP-2.5-SM/LC EEC 942 164-001
M-SFP-2.5-SM+/LC EEC 942 165-001
Gigabit Ethernet SFP transceiver Order number
M-SFP-TX/RJ45 943 977-001
M-SFP-TX/RJ45 EEC 942 161-001
The following operating conditions apply to twisted pair transceivers:
 Usable with:
- HiOS as of software version 03.0.00
- Classic Switch software, as of software version 04.1.00.
- HiSecOS as of software version 01.2.00
Do not use with the following devices:
- SPIDER II- MSP/MSM
- EES
 Longer RSTP switching times and link loss detection times compared to twisted pair ports
provided by the device directly.
 Not applicable for combo and Fast Ethernet ports.
 Only support of the autonegotiation mode including autocrossing.
M-SFP-SX/LC 943 014-001
M-SFP-SX/LC EEC 943 896-001
M-SFP-MX/LC EEC 942 108-001
M-SFP-LX/LC 943 015-001
M-SFP-LX/LC EEC 943 897-001
M-SFP-LX+/LC 942 023-001
M-SFP-LX+/ LC EEC 942 024-001
M-SFP-LH/LC 943 042-001
M-SFP-LH/LC EEC 943 898-001
M-SFP-LH+/LC 943 049-001
M-SFP-LH+/LC EEC 942 119-001
SFP-GIG-LX/LC
a
a. You find further information on certifications on the Internet at the Hirschmann product
pages (www.hirschmann.com).
942 196-001
SFP-GIG-LX/LC EEC
a
942 196-002
Bidirectional Gigabit Ethernet SFP transceiver Order number
M-SFP-BIDI Type A LX/LC EEC 943 974-001
M-SFP-BIDI Type B LX/LC EEC 943 974-002
M-SFP-BIDI Type A LH/LC EEC 943 975-001
M-SFP-BIDI Type B LH/LC EEC 943 975-002
M-SFP-BIDI Bundle LX/LC EEC (type A + B) 943 974-101
M-SFP-BIDI Bundle LH/LC EEC (type A + B) 943 975-101
