PowerMICE
Release
01
04/2014
21
MM22-T1T1T1T1 PoE media module
The MM22-T1T1T1T1 PoE media module (deeper module design)
supports Power over ETHERNET (PoE) according to IEEE 802.3af. It
allows the connection and remote supply of IP telephones (Voice over IP),
webcams, sensors, printer servers and WLAN access points via 10BASE-
T/100BASE-TX, for example. With PoE, these terminal devices are
powered by the twisted-pair cable.
The MM22-T1T1T1T1 media module has four 10BASE-T/100BASE-TX
ports (RJ45 connections) for connecting network segments or PoE
terminal devices (PD, Powered Device) up to class 0 (or respectively
class 3).
The current is supplied on the free line pair (spare pairs); the individual
ports are not electrically insulated from each other.
The following conditions are met in accordance with IEEE 802.3af:
Endpoint PSE
Alternative B.
MM4 media modules
The 4-port MM4-4TX/SFP media module has 4 TP interfaces and 4
sockets for SFP modules from Hirschmann.
The 2-port MM4-2TX/SFP media module has 2 TP interfaces and 2
sockets for SFP modules from Hirschmann.
The Gigabit slot of the PowerMICE (slot on the left side next to the switch
basic module) supports two Gigabit ports.
When you use an SFP module, you get an optical interface. You thus
deactivate the corresponding TP interface.
Note: Only use SFP modules from Hirschmann (see page 54
“Accessories”).
MM4 media modules
Module type
TP ports
10/100/1000
SFP ports
as alternatives to TP
ports
MM4 - 2TX/SFP 2, RJ45 2
MM4 - 4TX/SFP 4, RJ45 4
Table 3: Media connections per MM4 media module (number and type)
