Figure 2-4
2.2
2.22.2
2.2 Inspection of spark Plug
1. Unplug the Spark-Plug cap:remove
the spark plug by box key,look over
whether the spark-plug insulator and
electrode is damaged or sooting.
If so ,see figure 2-5. Figure 2-5
2． Check the spark clearance
by feeler gauge whether it
is between 0.6～0.7mm.Or adjust
the gap,clean incrustation
with spark-plug cleaner and steel
wire brush and check if
the spark plug sealing
washer(Figure 2-6). Figure 2-6
.
