Hisun 700UTV - Engine Disassembly; 3.1 Cylinder Head and Block

27
7. Inspection of rocker arm shaft.
Examine if the rocker arm if worn out or cracked.
Measure the external diameter of rocker arm shaft with
micrometer.
Repairing limit value: φ11.96mm
The repairing limit value of clearance between rocker arm
shaft and hole : 0.05mm ,See figure 2-25
Figure 2-25
3.
3.3.
3. disassembly of engine
3.1
3.1 3.1
3.1 cylinder head and block
① Unplug the intake pipe and spark plug.( Figure 2-26-1,
