needle bearing55BM6720 5、
initiative gear 6、
sulcate ball bearing6206c3-22 7、
rear disk brake install seat 8、
rear case import axes oil envelop 9、
needle bearing55BM6720 10、
rear case initiative gear "O" ring 11、
Ⅰrear retarder adjustment gasketⅠ 12、flange nut M12 13、rear disk brake leading
install plate 14、drive piston gasket（0.25T）drive piston gasket（0.30T）drive
piston gasket （0.35T）drive piston gasket（0.40T）drive piston gasket（0.45T）
drive piston gasket（0.50T） 15、bolt M8×20 16、gasketф8.5 17、drive piston gasket
（0.25T）drive piston gasket（0.30T）drive piston gasket（0.35T） gasket with jack
（1.8T） gasket with jack（1.8T） 18、rear case oil filler hole bolt 19、oil filler
hole "O"ring 20、rear retarder pipe 21、retarder shell Ⅱ22、column axes boltM8 23、
gasketф8.5 24、flange nut M825、1rear case export axes oil envelop1 26、sulcate ball bearing
16017c2 27、rear case cover "O"ring 28、circle bearing（0.25T）circle bearing（0.30T）
circle bearing（0.40T）29、boltM8×25 30、gasket ф8.5 31、flange nutM10×22 32、
boltM8×30 33、gasket ф8.5 34、compression spring 35、rear bridge middle transmission
shaft 36、spring flange 37、rear bridge middle
transmission shaft connecting cover
(The service method of the rear bridge parts is as the same as
the front bridge parts, please refer to the before-mentioned
to operate.)
4.5.Reverse mechanism parts
.
