Hisun 700UTV - Page 26

26
Figure 2-23
7、Check whether the crankshaft journal is worn out and
measure the external diameter of crankshaft journal.
Repairing limit value: φ22.939mm
Inspection of rocker arm.
Check whether the rocker arm is worn out,or damaged and
whether the oil hole is blocked.
Note:If there is a rocker arm to be replaced,examine
the peak of breaker cam
measure the bore diameter of rocker arm
Repairing limit value: φ12.038mm.See figure 2-24
Figure 2-24
