23
0.05mm.See figure 2-19
Figure 2-19
2 Remove and examine the width of valve .
Repairing limit value: 2.0mm.
See figure 2-20-1 , 2-20-2, 2-20-3.
Figure 2-20-1 Figure 2-20-2
Figure 2-20-3
If the mating surfaces is coa
rse,corrode or cannot
contact with valve seat normally.repalce it.
