Attached figure4-2-1
b) )The brake pedal should be kept between 20mm-30mm,
Otherwise, please adjust the screw to meet required
travel distance.(Attached figure4-2-2)
Attached figure4-2-2
1. Brake pedal
Inspect the brake pedal does maintain the certain
counter-tension(Attached figure4-2-2)
When checks disk brake plate, the saved liquid in the oil cup
will pour automatically into the pressure pipe and the liquid
level along with it to reduce, the periodic inspection the disk
brake plate liquid volume will be an important project.
Attention,must use DOT4 Brake Flui
