Cable connection
Figure 21: APCQ-L power cables connection to busbars
– Connect CT cables.
CT
Figure 22: APCQ-L CT connection
5.4.6. APCQ-M and APCQ-R electrical connections – Bottom entry
The APCQ-M and APCQ-R cubicles are bottom cable entry by default.
3
