APCQ CAPACITOR BANKS
© 2022 Hitachi Energy. All rights reserved
12. Technical specifications
- 50Hz. For other voltages, please consult us.
380 / 480 / 600 / 690 V - 60 Hz For other voltages, please consult us
Working ambient conditions
5°C (23°F)/+40°C (104°F) according to EN 61921
Humidity: 95% max, not condensing
2000m (for higher altitudes, please consult us)
− APCQ-L: wall mounted, bottom cable entry
− Clearance lateral: not necessary - top and bottom: 200 mm
− APCQ-M and APCQ-R cubicles: free floor standing, bottom cable entry (top ca-
ble entry optional)
− Clearance lateral & back: 50 mm (but no clearance required between two
-phase, balanced network.
− IP23 (closed door) - optional IP54
− Protected against direct and accidental contact (open door)
-L: About 55 dBA (1m)
APCQ-M/R: About 70 dBA (1m)
From 0.7 inductive to 0.7 capacitive
Starting current setting (C/k)
From 0.01A to 3A for the RVC controller
From 0.01A to 5A for the RVT controller (optional)
During operation, RVC (RVT) controller displays:
− the number of active outputs
− the inductive or capacitive power factor
− the alarm conditions: target cos ϕ, over/undervoltage, THDV, overtemperature
− the demand for switching on/off a capacitor step
Without reactors: less than 1.5 W/kvar
With reactors: typical 5.5 W/kvar (7 W/kvar maximum in worst case)
– QCap type
-healing according to IEC 60831-1&2
Dielectric: 2.15 Un between terminals during 10 sec at ra
ted frequency
Acceptable overvoltage: +10% max. (maximum 8h/day) as per IEC 60831
-1
Acceptable overcurrent: +30% permanently
Temperature range: -25°C (-13°F) / class D according to IEC 60831-1&2
-R only) − Dry type resin embedded according to IEC 289, IEC 76
− Maximum harmonic pollution: 8% THDV with specific spectrum. Others under
-1&2 (capacitors)
50 kA (Icw 1 sec as per IEC 61921)
