4. Products overview and description
4.1. APCQ capacitor bank series
There are 3 types of APCQ capacitor banks:
– APCQ-L: wall-mounted cubicles without reactor,
– APCQ-M: free floor-standing cubicles without reactor,
– APCQ-R: free floor-standing cubicles with reactors.
All APCQ capacitor banks are available in master execution only, equipped by default with a RVC controller (RVT as
an option).
4.2. APCQ capacitor layouts
Standard APCQ cabinet layout are as per
Figure 5 below and is IP23 by default. IP54 optional design is possible, see 6.7.
Figure 5: APCQ IP23 standard layouts
Note: external layouts of APCQ-M and APCQ-R capacitor banks are identical.
APCQ-R/M
APCQ-L
